Software protection board lithium batteries, also known as intelligent lithium battery protection boards, are widely used in many fields due to their functional advantages such as precise monitoring and communication interaction. However, due to its functional complexity, various problems are also prone to occur. The following elaborates on the corresponding solutions for five common problems in detail.
I. The issue of inaccurate data monitoring
Problem manifestation
The data displayed on the state of charge (SOC) and health status (SOH) of the battery deviate significantly from the actual situation, leading users to misjudge the battery status and affecting the use of the equipment or battery management decisions.
Cause analysis
Sensor failure: The sensors responsible for collecting battery parameters, such as voltage sensors and current sensors, age or get damaged, resulting in distorted collected data.
Algorithm defect: The data calculation algorithm built into the protection board is unreasonable and cannot accurately calculate the battery status parameters based on the actual working conditions.
Data transmission interference: Communication lines are subject to electromagnetic interference, or there are loopholes in the data transmission protocol, resulting in data loss or errors during transmission.
Solution method
Detection and replacement of sensors: Use professional instruments to calibrate and test the sensors. If the performance of the sensors declines or they are damaged, replace them with sensors of the same specification and high precision in a timely manner.
Optimization algorithm: Based on the actual characteristics and application scenarios of lithium batteries, the data calculation algorithm of the protection board is optimized and upgraded. By cooperating with lithium battery manufacturers, more accurate battery parameters can be obtained, thereby enhancing the accuracy of the algorithm calculation.

Anti-interference processing and protocol optimization: Shield communication lines to reduce electromagnetic interference; Check the data transmission protocol, fix the existing vulnerabilities, and replace it with a more stable and reliable communication protocol if necessary, such as upgrading the SPI protocol to the CAN protocol, to enhance the stability and accuracy of data transmission.



Ii. Abnormal communication issues
Problem manifestation
The protection board cannot communicate normally with external devices (such as the main control system of the device or the upper computer), making it impossible to achieve data interaction and collaborative control. This results in users being unable to obtain battery status information or remotely manage the battery.
Cause analysis
Communication interface damage: The communication interfaces of the protection board (such as USB interfaces, serial ports, etc.) are physically damaged due to external force impact, oxidation, etc., and cannot be normally connected to external devices.
Communication protocol incompatibility: The communication protocols used by the protection board and external devices are inconsistent, or there are differences in protocol versions, resulting in the inability of both parties to recognize and parse the data sent by each other.
Driver issue: The driver of the external device is not installed correctly, or the driver version is too low to communicate effectively with the protection board.
Solution method
Repair or replace communication interfaces: Check the physical condition of communication interfaces. For minor oxidation, poor contact and other issues, special tools can be used for cleaning and repair. If the interface is severely damaged, replace it with a new communication interface.
Unified communication protocol: Confirm the communication protocol supported by the protection board and external devices. Through software upgrades or Settings, ensure that both parties adopt the same communication protocol and version to guarantee the correct transmission and parsing of data.
Update the driver: In the operating system of external devices, update the driver corresponding to the protection board. You can download the latest version of the driver from the official website of the device manufacturer, install it, and then try the communication connection again.
Iii. Battery balancing failure Issues
Problem manifestation
In a battery pack composed of multiple lithium batteries, the voltage differences among individual battery cells gradually increase, and the battery balancing function of the protection board fails to work properly, resulting in a decline in the overall performance of the battery pack and a shortened service life.
Cause analysis
Balancing circuit failure: In the balancing circuit of the protection board, if components such as balancing resistors and MOSFETs are damaged, or if there are problems such as open circuits or short circuits in the circuit, the balancing function cannot be achieved.
Improper control strategy: The control strategy for battery equalization is unreasonable. For instance, the equalization start-up threshold is set too high, resulting in the initiation of equalization only when there is a significant voltage difference among individual battery cells, or the equalization time is set too short, failing to achieve an effective equalization effect.
Software program error: The software program of the protection board that controls battery balancing has loopholes or errors, and cannot correctly control the operation of the balancing circuit.
Solution method
Inspect the balancing circuit: Use tools such as multimeters and oscilloscopes to test the balancing circuit, identify faulty components or circuit issues, replace damaged components, and repair circuit faults.
Optimize control strategy: Based on the actual situation of the battery pack, reasonably adjust the control strategy for battery equalization, lower the equalization start-up threshold, extend the equalization time, and ensure that the voltage of individual battery cells can reach the equalization state in a timely and effective manner.
Repair software programs: Inspect and debug the software programs of the protection board, fix program vulnerabilities related to the battery balancing function, and rewrite or upgrade the software programs if necessary.
Iv. Issues of failure in self-diagnosis and fault early warning
Problem manifestation
When potential faults occur in lithium batteries or protection boards, the protection boards are unable to conduct self-diagnosis in a timely manner and issue early warning information, resulting in users being unable to detect and handle problems promptly and increasing the operational risks of the equipment.
Cause analysis
The fault detection algorithm is not perfect: The built-in fault detection algorithm of the protection board cannot accurately identify certain types of faults, or the threshold for fault judgment is set unreasonably, resulting in missed detection or misjudgment of faults.
Early warning module damage: The sound and light alarm module, communication alarm interface and other early warning modules of the protection board have malfunctioned and cannot issue early warning signals normally.
Software logic error: In the software logic for fault early warning, there are process errors or incorrect condition judgments, which prevent the early warning function from being triggered normally.
Solution method
Improve the fault detection algorithm: Collect common fault types and characteristic data of lithium batteries and protection boards, optimize the fault detection algorithm, enhance the algorithm's ability to identify various faults, reasonably adjust the fault judgment threshold, and reduce missed detection and misjudgment.
Maintenance early warning module: Check the hardware status of the early warning module and replace damaged components, such as light-emitting diodes, buzzers, etc. Fix the fault of the communication alarm interface to ensure that the early warning signal can be transmitted normally.
Correct software logic: Conduct a comprehensive inspection and correction of the software logic related to fault early warning to ensure that when a fault is detected, the early warning function can be triggered in accordance with the correct process.
V. Software upgrade Failure Issues
Problem manifestation
When upgrading the software of the protection board, problems such as upgrade interruption and the inability of the program to run normally after the upgrade occurred, affecting the normal functions and performance of the protection board.
Cause analysis
Unstable power supply during the upgrade process: During the software upgrade process, if there are fluctuations or power outages in the power supply, it will cause the upgrade to be interrupted and damage the program files.
Upgrade file error: The downloaded software upgrade file is incomplete, the version does not match, or the file was tampered with during transmission, resulting in the program being unable to run normally after the upgrade.
Upgrade tool or communication issues: The upgrade tool used is incompatible, or the communication line malfunctions during the upgrade process, making it impossible to correctly write the upgrade file into the control IC of the protection board.
Solution method
Ensure stable power supply: Before performing software upgrades, check the power supply situation and use a stable power adapter to power the protection board to avoid power supply abnormalities during the upgrade process.
Verify the upgrade file: Download the software upgrade file from the official channel and verify the completeness and version of the file. This can be achieved through methods such as comparing the file's hash value to ensure its accuracy.
Check the upgrade tool and communication: Use an upgrade tool compatible with the protection board and check the connection of the communication line before the upgrade to ensure normal communication. If the upgrade fails, you can try re-downloading the upgrade file, changing the upgrade tool or communication interface, and then perform the upgrade operation again.
